A&D AD-4212B-101 Weigh Module, 31 g / 110 g × 0.01 mg / 0.1 mg

The A&D AD-4212B-101 is the smart-range production weigh module: 31 g × 0.01 mg and 110 g × 0.1 mg, Ø34 mm pan, separate 80 mm sensor, about 2 m display cable, RS-232 and comparator output. Not AD-4212B-102 (110 g × 0.01 mg only) and not AD-4212B-23 (21 g × 0.001 mg).
Manufacturer: A&D AD-4212B and the A&D AD-4212B datasheet.
What is in the box
AD-4212B-101 weighing unit and display unit
About 2 m connection cable
Ø34 mm pan
50 g OIML Class E2 calibration weight
AC adapter
Instruction manual
Verified specs

Brand
A&D Weighing
Model
AD-4212B-101
Product Type
Production weigh module
Capacity × readability
31 g × 0.01 mg / 110 g × 0.1 mg (smart range)
Repeatability
0.05 mg / 0.1 mg
Linearity
±0.05 mg / ±0.2 mg
Stabilization (FAST)
About 4.0 s / 2.5 s
Pan
Ø34 mm
Calibration
External; 50 g Class E2 weight included
Interfaces
RS-232C; 3- or 5-level comparator with buzzer
Cable length
About 2 m between weighing unit and display
Weighing unit
80 × 230 × 90 mm / about 2.3 kg
Display unit
237 × 150 × 155 mm / about 2 kg
Power
AC adapter (about 15 VA)
IP
IP54 (weighing unit)
NTEP (this SKU)
No — production module, not a legal-for-trade bench

Applications
Automated filling and checkweigh
Vacuum-chamber or in-line precision weighing
OEM production systems
Questions before you order
Questions on compatibility, calibration, or what is in the box? All Scales USA, 21249 FM 529 Rd, Cypress, TX 77433. Call (832) 766-5410 or email pete@allscales.com. Also: (281) 656-2666 · (832) 290-3120.
