A&D HT-500CL Compact Comparator, 510 g × 0.1 g
The A&D HT-500CL compact comparator scale weighs up to 510 g in 0.1 g increments. Red, green and yellow LO/OK/HI lights help you check portions or packs against preset weight limits.
- Nine sets of upper and lower comparison limits
- Clear 13.5 mm LCD and key-lock function
- AC adapter and stackable carrying case included
- Optional battery operation with four AA cells
Specifications
Brand A&D Weighing Model HT-500CL Offer quantity 1 scale Capacity × readability 510 g × 0.1 g Calibration External; specified mass 500 g ±0.01 g (sold separately) Weighing pan 132 × 130 mm; HT-10 stainless-steel pan optional Display 13.5 mm LCD; separate red LO / green OK / yellow HI comparator LEDs Repeatability (standard deviation) 0.1 g Non-linearity ±0.2 g Display update Approximately 10 times per second Comparator memories 9 sets of upper/lower limits Weighing units g, oz, ozt, lb-oz, dwt, ct, tola, N; selectable tael type Power Included AC adapter or four AA batteries (batteries sold separately) Alkaline battery life Approx. 450 hours with comparator disabled or 220 hours continuously displaying red, at 23°C; varies with conditions Dimensions (W × D × H) 136 × 195 × 47 mm, per instruction manual Net weight Approximately 470 g excluding batteries Auto power off Approximately 5 minutes while the reading remains stable; can be disabled Operating environment −10°C to 40°C; below 85% relative humidity, non-condensing Data connections No computer/printer data interface specified for this model Trade use General-purpose weighing; not offered here as NTEP legal-for-trade equipment Warranty 2-year limited What's Included
- HT-500CL scale
- AC adapter suitable for the supplied region
- Stackable carrying case
- Name plate and three color bars
- Operating-instruction sticker and manual
Four AA batteries, the HT-10 stainless-steel pan and the 500 g calibration weight are sold separately. Confirm local voltage and plug type before using the adapter.
Applications & Industries
- Portion and package weight checks
- Weight-limit sorting
- Take-away weighing with supported software
Calibration & Connections
Use an external 500 g calibration weight with ±0.01 g tolerance, purchased separately. The comparator cannot be used in lb-oz or tael modes. For take-away checkweighing, follow the supplementary instructions, which apply to software p-1.01 and later, and re-zero the filled container before measurement.
No USB, RS-232C or printer connection is specified. Do not assume that an A&D cable or converter adds data output to this scale.
Contact Us
Need help choosing accessories or a calibration weight? Contact All Scales USA, 21249 FM 529 Rd, Cypress, TX 77433.
Call (832) 766-5410 or email pete@allscales.com. Additional numbers: (281) 656-2666 and (832) 290-3120.
Product Photos
HT-CL family reference photos are shown. The angled instrument is an HT-5000CL; this offer is for the HT-500CL, rated 510 g × 0.1 g. The case photo includes the optional stainless-steel HT-10 pan, sold separately.
Model
HT-500CLProduct Type
Digital Scales
