A&D MX-50 Moisture Analyzer, 51 g × 0.001 g
The A&D MX-50 measures moisture by heating a sample and tracking its weight loss. Save drying methods for repeat loss-on-drying tests and review results on a connected Windows PC.
Free shipping within the contiguous U.S.
Specifications
Manufacturer / model A&D MX-50 Maximum sample capacity 51 g Weighing readability 0.001 g Moisture display resolution Selectable 0.01% or 0.1% Moisture repeatability (standard deviation) 0.10% for samples over 1 g; 0.02% for samples over 5 g Drying temperature 50–200 °C in 1 °C increments Heating system 400 W straight halogen lamp with Secondary Radiation Assist (SRA) Weighing sensor Super Hybrid Sensor (SHS) Sample pan 85 mm diameter Heating patterns Standard, quick, step and ramp Measurement programs Standard, automatic, quick, timer and manual Memory 20 measurement programs; 100 results Results Wet-basis or dry-basis moisture, dry content, ratio and weight Display Vacuum fluorescent display (VFD) Interface RS-232C; USB requires an optional converter Dimensions (W × D × H) 215 × 320 × 173 mm Net weight Approximately 6 kg, excluding accessories Warranty 5-year manufacturer warranty, subject to A&D warranty terms Moisture repeatability is a standard-deviation specification. Results depend on the sample and drying method.
Included Items
- MX-50 moisture analyzer
- 20 sample pans and 2 pan handles
- Tweezers and spoon
- 30 g sodium tartrate dihydrate test sample
- Glass fiber sheet
- WinCT-Moisture software
- RS-232C cable
- Display cover and dust cover
- Power cable and fuse
- Instruction manual and quick-reference card
Applications & Industries
- Food / pharmaceutical moisture
- Chemical and process solids
- Loss-on-drying QC
Establish the drying method for your sample and follow the manual’s preparation and safety instructions before testing.
Calibration & Optional Accessories
Weighing calibration uses an external 20 g or 50 g mass. Temperature calibration is supported with the optional A&D temperature calibrator. Calibration weights, the temperature calibrator, USB converter, printer and extra consumables are sold separately.
Use the supply voltage printed on the instrument’s rear label; the 100–120 V and 200–240 V versions are different.
Manuals & Documentation
