MNM Scales GX-1-2.5K Shear Beam Load Cell, 2,500 lb, NTEP

The MNM Scales GX-1-2.5K is a 2,500 lb alloy-steel shear beam for floor, tank, and hopper kits. This carton includes a foot, a spacer, and a 20 ft cable. Confirm hole pattern against the cell you are replacing.
Keep this alloy GX-1-2.5K carton separate from the stainless GX-1-SH-2.5K washdown sibling.
What is in the box
GX-1-2.5K 2,500 lb alloy-steel shear beam
One foot
One spacer
20 ft cable
Verified specs

Brand
MNM Scales
Model
GX-1-2.5K
Product Type
Shear-beam load cell
Capacity
2,500 lb
Construction
Alloy steel
Rated output
3 mV/V
Cable
20 ft, 4-wire (red+/black− input, green+/white− output)
Hardware
One foot and one spacer
NTEP
Yes — NTEP shear-beam component. CoC number not printed on this page.
Use
Floor, platform, tank, and hopper kits
In the carton
GX-1-2.5K cell, foot, spacer, 20 ft cable

Applications
Replace a 2,500 lb alloy shear beam on a floor scale
Build or repair a tank or hopper kit that uses this hole pattern
Platform and bench-scale retrofits
Questions before you order
Questions on compatibility, calibration, or what is in the box? All Scales USA, 21249 FM 529 Rd, Cypress, TX 77433. Call (832) 766-5410 or email pete@allscales.com. Also: (281) 656-2666 · (832) 290-3120.
